DG832
35MHz 2 channel,125MSa/s sample rates,16bit resolution,2Mpt memory depth,7digits/s counter
The DG832 is a 35MHz, 2CH Function Generator with a maximum sampling rate of 125MSa/s. The Rigol DG800 series offers a user-friendly and high-performance function/arbitrary waveform generator solution at a very attractive price. Each instrument provides many functions including; function generator, arbitrary waveform generator, noise source, pulse generator, harmonics generator, analogue / digital modulator and frequency counter.
Unique SiFiII (Signal Fidelity II) technology
Two fully functional and independent channels (optional upgrade on single-channel models)
Maximum frequency 35MHz
125MSa/s sample rate
16-bit vertical resolution
Basic waveforms: Sine, square, ramp, pulse, noise, DC, dual-tone
Advanced waveforms: PRBS, RS232, sequence
160 built-in arbitrary waveforms
Up to 8Mpts (optional) arbitrary waveform memory, 2Mpts standard
Supported modulation: AM, FM, PM, ASK, FSK, PSK & PWM
