DG972

2 channel function / arbitrary waveform generator with 1 ?Hz to 100 MHz bandwidth, 250 MSa/s samplerate, 16 Bit resolution, 16 Mpts memory depth, amplitude range 1 mVpp to 1 Vpp (high impedance), 10.9 cm (4.3") touchdisplay.

100 MHz function / arbitrary waveform generator
16 Mpts memory depth per channel for arbitrary waveforms
Dual-channel performance is equivalent to two independent signal sources
High frequency stability: ?1 ppm; low phase noise: -105 dBc/Hz
Built-in high-order harmonic generator (at most 8-order harmonics)
Built-in 7 digits/s, 240 MHz bandwidth full featured frequency counter
160 built-in arbitrary waveforms, covering common signals in engineering, medical and automotive electronics, math processing, and more
