DSG815

9kHz-1.5GHz,-100dBc/Hz Phase Noise,+13dBm to -110dBm, Amplitude Accuracy<0.5dB, 2ppm

SKU: DSG815 Category: RF Signal Generator Tags: dsg815, generator, signal

Product categories

Barrett Communications (6)
Bluetti (17)
Grandstream Networks (254)
Lamatel (172)
Mikrotik (277)
Motorola Solutions (414)
Rigol (416)
- Accessories and Options (11)
- Data Acquisition (21)
- Data Acquisition/Switch System (3)
- DC Electronic Load (17)
- DC Power Supply (28)
- Digital Multimeter (8)
- Digital Oscilloscope (187)
- Function/Arbitrary Waveform Generator (36)
- RF Signal Generator (20)
- Spectrum Analyzer (68)
- Waveform Generator (17)
Uncategorized (1)

Description

The DSG815 RF signal generator offers standard AM/FM/?M analog modulation, as well as options for pulse modulation with a maximum frequency 1.5 GHz. Featuring a high signal purity with phase noise measuring <-105 dBc/Hz @ 20 kHz (typical) and a wide output range of -110 dBm to +13 dBm, the DSG800 RF signal generator has an optional pulse modulation with an on/off ratio of up to 70dB, with optional pulse train generator available. The DSG800 series also has an amplitude accuracy of < 0.5 dB (typical). Beside the analog output the devices include a USB-Host- and a USB-device and a LAN interface.
